1. DC24V Power Input (5.08 PITCH)

2. Power Supply Reverse Polarity Protection Provided

3. 24 INPUTS

   1. 2-wire input type, supports up to 10mA current drive

   2. 3-wire input type, current supplied by external power source

   3. ESD protection provided for each input point

4. 16 OUTPUTS

   1. 4 opto-isolated FET outputs, each supports up to 1A continuous output (up to 9A peak)

   2. 8 relay outputs, each supports up to 8A continuous output

   3. Supports inductive load

5. EFT Test: Coupling 3kV, Power Supply 3kV

6. Removable European-style 5.08 PITCH terminal blocks

7. Foolproof design for INPUT (8PIN) / OUTPUT (4PIN) connectors

8. 26PIN universal axis control interface, fully compatible with A6 series controller interface definitions
